Characteristics:
1. Main motor frequency conversion adjust speed(0~4000 r/m adjust)
2. Small value of reduction of speed,large output torque
3. High measurement accuracy
4. The function of overvoltage, overload and short circuit
5. Many kinds of rotation speed presetting
6. Constant temperature controlled
7. Ultra low noise
8. Buit-in air suppply
9. Touch screen operation mode
10. Built –in lube system(optional)
11. Advanced angle,rotation speed,count,temperature,
pressure,rack bar are displayed on 17〞LCD(optional)
12. Large-scale data base,search and print easily(optional)
13. Screen display and digital display operation mode
Functions:
1. Test each cylinder’s oil supply capacity at various rotation speed
2. Test each cylinder’s injection time with static state
3. Test the mechanical speeds governor
4. Test electromagnetic valve of distribution pump
5. Check pressure compensators
6. Test the sealing performance of injection pump
7. Test the oil-return quantity of distribution pump
8. Test inner pressure distributor pump.
9. Checking of the pneumatic speed governor’s vacuum performance
10. Twelve kinds of rotation speeds presetting
11. Measurement of rack travel（optional）.
12. Measurement of advance angle(optional).
13. Large-scale data base,search and print easily
(optional)
14. Test the injection angle of lube (optional)
Technical parameters:
1. Rotation speed:0~4000 r/m
2. Double series of graduates:45cc,150cc(as request)
3. Volume of diesel fuel tank:60L
4.Temperature autocontrol: 40±2℃
5.Test oil filtering unit: 5μ
6. D.C. supply:12V/24V
7. Feed pressure:low:0~0.4Mpa high:0~4Mpa
8.Air pressure:positive :0~0.25Mpa Negative:-0.05~0Mpa
9. Volume of motor oil tank:40L(optional)
10. Motor oil adjust pressure:0~1Mpa(optional)
11.Flywheel inertia: 0.8KG·M2
12. Center height:125mm
13.3 phase power resource:380V/50Hz or as request
14.Output power resource: 5.5KW、7.5KW、11KW、15KW、18.5KW or as request
|
|
|
|
|
