Oil quantity measurement display by screen
1. System Application:
the system is suitable for detection of BOSCH,DENSO, DELPHI and SIEMENS common rail pump, rail and injectors. Such as CP1,CP2, CP3, HP3 series injector pump and many kinds of injectors.
2. Technical parameters:
1). Main motor speed: 0-4000 r/min can be adjustable.
2). Motor power : 7.5KW, 11KW, 15KW, 18.5KW optional.
3).Fuel Injector open voltage:
Control range: 12V, 80V, 150V
Control accuracy : phase adjustment
4). Injector opening frequency:
Control: 0-1000Hz
Control accuracy: 1Hz
5). Fuel Injector Hold Time:
Control: 0-65535us
6). Delivery Oil Count:
Control: 0-1000 times
Control accuracy: 1 times
7). Fuel pressure control
Control:0-2000 bar
Control accurancy: 1bar
8).Electronic power : 3Phase 380V or 3 Phase 220V optional
